Exterior Storm Window Shutters
EMG&YEMAG has specialized designs and production of Exterior hurricane shutters. Hurricane-resistant specialized products especially in places where hurricanes are frequent or in areas surrounded by the sea. Aluminum extruded slats 32mm, 37mm, 55mm, 56mm, 77mm, 100mm, 120mm, 140mm specifications. The side rails on both sides of the product are also specially designed to resist hurricanes. Motorized drive, switch or remote control.
Product introduction
EMG&YEMAG hurricane-resistant, secure and burglar-proof aluminum roll-up window and door series. The slats are extruded aluminum profiles and the products are professionally designed.
No.: EMG07-033589-55SP
Product Name: 55mm windproof slats( aluminum extrusion slats)
|
Thickness |
11.3mm |
|
Weight |
5.6Kg/m² |
|
Maximum production width |
4.0m |
|
Maximum production height |
3.5m |
|
Maximum production area |
12m² |
|
Number of profiles per meter height |
18 pcs. |
|
Surface treatment |
Powder coating |
|
Color |
White (other colors can be customized according to the quantity) |
|
Style |
Without holes, with holes (2%) |
No.: EMG12-068121-56F-SK
Product Name: 56mm windproof slats( aluminum extrusion slats)
| Thickness | 14.5mm |
| Weight | 12.3kg/m² |
| Maximum fabrication width | 6.0m |
| Maximum fabrication height | 4.0m |
| Maximum production area | 22m² |
| Number of profiles per meter height | 18 |
| Surface treatment | powder spraying |
| Color | white, beige, gray |
| (other colors can be customized according to the quantity) Style | without hole |
No.: EMG11-071920-77SP
Product Name: 77mm windproof slats (Aluminum extrusion slats)
| Thickness | 18.4mm |
| Weight | 9.2Kg/m² |
| Maximum production width | 6.5m |
| Maximum production height | 6.5m |
| Maximum production area | 35m² |
| Number of profiles per meter height | 13 pcs. |
| Surface treatment | powder coating |
| Color | white (other colors can be customized according to the quantity) |
| Style | without holes |
No.: EMG09-063813-77SP-PU
Product Name: 77mm windproof slats( aluminum extrusion slats with Polyurethane Filling)
| Thickness | 18.4mm |
| Weight | 9.2Kg/m²(Polyurethane weight not included) |
| Maximum production width | 6.5m |
| Maximum production height | 6.5m |
| Maximum production area | 35m² |
| Number of profiles per meter height | 13 pcs. |
| Surface treatment | powder coating |
| Color | white (other colors can be customized according to the quantity) |
| Style | without holes |
No.: EMG20-063809-77DP
Product Name: 77mm windproof slats( aluminum extrusion slats)
| Thickness | 17.5mm |
| Weight | 8.0Kg/m² |
| Maximum production width | 5.5m |
| Maximum production height | 4.0m |
| Maximum production area | 20m² |
| Number of profiles per meter height | 13 pcs. |
| Surface treatment | powder coating |
| Color | white (other colors can be customized according to the quantity) |
| Style | without holes, with holes (Porous: 17%) (Round hole: 21% (Square holes: 20%) |
No.: EMG12-1441194-120SF
Product Name: 120mm windproof slats( aluminum extrusion slats)
| Thickness | 25.5mm |
| Weight | 12.0Kg/m² |
| Max. production width | 9.0m |
| Maximum production height | 7.8m |
| Max. production area | 65m² |
| Number of profile roots per meter height | 8 |
| Surface treatment | powder coating |
| Color | white, beige, gray (Other colors can be customized according to the quantity) |
| Style | without h |
basic color
For all the visible surfaces of our products made of aluminum, we offer five common color combinations or customized by RAL colors. The color scheme will always match your building space perfectly.
